Z Beam Load Cell
LC226B
The Saintbond z beam load cell is a high-precision strain gauge sensor designed for tension and compression measurements. Z beam load cell 200kg ideal for industrial scales, hoppers, and force monitoring, Z beam load cell features robust construction, IP65 protection, and multiple output options (mV/V, 4-20mA, RS485). Ensures accurate, reliable performance in harsh environments.
Quantity:
The Saintbond z beam load cell is a high-precision strain gauge sensor designed for tensionandcompression measurements. Z beam load cell 200kg ideal for industrial scales, hoppers, and force monitoring, Z beam load cell features robust construction, IP65 protection, and multiple output options (mV/V, 4-20mA, RS485). Ensures accurate, reliable performance in harsh environments. ( z beam load cell, Saintbond z beam load cell, load cell 200kg )
LC226B Z Beam Load Cell Product Description:
✅ The S Beam Load Cell offers a compact design for platforms, silos, or scales. The Standard LC226B S Beam Load Cell model has female threads.
✅ S Beam Load Cell has a high accuracy. This s beam Load Cell can be modified or customized to meet your requirements.
✅ Standard ranges are from 25kg~200kg. Electrical output is 2mV/V with options for amplified outputs of 4-20mA, 0-5VDC, 0-10VDC or +/-10VDC.
LC226B Z Beam Load Cell Applications:
Suspended tanks and hoppers, crane scale. Suitable for general applications in the process weighing and process automation and control sectors.
LC226B Z Beam Load Cell Dimension:
| Cap/Size | A | B | C | H | T |
| 20~150kg | 70 | 12 | 76 | 64 | M8 |
| 200~500kg | 70 | 20 | 76 | 64 | M12 |
| 0.75~1t | 70 | 25 | 76 | 64 | M12 |
| 1.5~5t | 90 | 32 | 95 | 90 | M20 |
| 7.5~10t | 90 | 40 | 95 | 90 | M24 |
LC226B Z Beam Load Cell Technical Parameter:
| Rated Load: | 25/50/100/200kg | ||
| Sensitivity: | (2.0±0.1%)mV/V | Operating Temp.Range: | -30~+70℃ |
| Combined Error: | ±0.02% F.S | Maximum Safe Over Load: | 150%F.S |
| Creep Error (30min): | ±0.02% F.S | Ultimate Over Load: | 300%F.S |
| Zero Balance: | ±1% F.S | Recommend Excitation Vol.: | 10~12V DC |
| Temp. Effect On Zero: | ±0.05% F.S/10℃ | Maximum Excitation Vol.: | 15V DC |
| Temp. Effect On Span: | ±0.05% F.S/10℃ | Sealing Class: | IP67 |
| Input Resistance: | 400±15Ω | Element Material: | Alloy /Stainless Steel |
| Output Resistance: | 350±3Ω | Cable: | Length=L:6m |
| Insulation Resistance: | ≥5000MΩ | Citation: | CE |
