Load Dynamometer
LCSW7
Load Dynamometer / hanging scale load cell – A high-precision, cable-free solution for real-time weight monitoring in industrial, logistics, and smart agriculture applications. Load Dynamometer designed for durability and long-range wireless communication, it ensures reliable data transmission even in harsh environments. With low power consumption and extended battery life, it enables seamless integration into IoT systems for efficient load tracking and management. Easy to install, maintenance-free, and compatible with various platforms.
Quantity:
Load Dynamometer / hanging scale load cell – A high-precision, cable-free solution for real-time weight monitoring in industrial, logistics, and smart agriculture applications. Load Dynamometer designed for durability and long-range wireless communication, it ensures reliable data transmission even in harsh environments. With low power consumption and extended battery life, it enables seamless integration into IoT systems for efficient load tracking and management. Easy to install, maintenance-free, and compatible with various platforms. ( load dynamometer, crane load sensor, hanging scale load cell, loadlink download for pc )
LCSW7 Load Dynamometer Features:
✅ Rugged construction.
✅ Accuracy: 0.05% of capacity.
✅ All functions and units are clearly display on the LCD (with backlighting) .
✅ Digits are 1 inch high for easy distant viewing.
✅ Two user programmable Set-Point can be used for safety and warning applications or for limit weighing.
✅ Long battery life on 3 standard “LR6(AA)”size alkaline batteries.
✅ All commonly used internationally recognized units are available : kilograms(kg), short Tons(t) pounds(lb), Newton and kilonewton(kN).
✅ Infrared Remote control easier to calibration(with password).
✅ Infrared Remote control with many functions : “ZERO”, “TARE”, “CLEAR”, “PEAK”, “ACCUMULATE”,“HOLD”, “Unit Change”, “Voltage Check” and “Power OFF”.
✅ 4 local mechanical keys :“ON/OFF”, “ZERO”, “PEAK” and “Unit Change”.
✅ Low battery warning;
✅ Hazardous area Zone 1 and 2
✅ Built-in-display option
✅ Available with a range of displays to suit each application
✅ Environmentally sealed to IP67 or IP68
✅ Can be used singularly or in sets
LCSW7 Crane Load Sensor Specifications:
| Rate Load: | 1/3/5/12/25/35/50/55/85/100/150/200/250/300/500t | ||
| Battery Type: | 18650 rechargeable batteries or polymer batteries (7.4v 2000 Mah) | ||
| Proof Load: | 150% of rate load | Max. Safety Load: | 125% F.S. |
| Ultimate Load: | 400% F.S. | Battery Life: | ≥40 hours |
| Power On Zero Range: | 20% F.S. | Operating Temp.: | - 10℃ ~ + 40℃ |
| Manual Zero Range: | 4% F.S. | Operating Humidity: | ≤85% RH under 20℃ |
| Tare Range: | 20% F.S. | Remote Controller Distance: | Min.15m |
| Stable Time: | ≤10seconds; | System Range: | 100~300m(Open Area),800~1500m (Optional) |
| Overload Indication: | 100% F.S. + 9e | Telemetry Frequency: | 430MHz to 470MHz |
LCSW7 Crane Load Sensor Cell Dimension:
| Model | Cap. | Div | A | B | C | D | φ | H | Material |
| ( Ton ) | (Kg) | (mm) | (mm) | (mm) | (mm) | (mm) | (mm) | ||
| LCSW6-01 | 1t | 0.5 | 245 | 112 | 37 | 190 | 43 | 335 | Aluminum |
| LCSW6-02 | 2t | 1 | 245 | 116 | 37 | 190 | 43 | 335 | Aluminum |
| LCSW6-03 | 3t | 1 | 260 | 123 | 37 | 195 | 51 | 365 | Aluminum |
| LCSW6-05 | 5t | 2 | 285 | 123 | 57 | 210 | 58 | 405 | Aluminum |
| LCSW6-10 | 10t | 5 | 320 | 120 | 57 | 230 | 92 | 535 | Alloy Steel |
| LCSW6-20 | 20t | 10 | 420 | 128 | 74 | 260 | 127 | 660 | Alloy Steel |
| LCSW6-30 | 30t | 10 | 420 | 138 | 82 | 280 | 146 | 740 | Alloy Steel |
| LCSW6-50 | 50t | 20 | 465 | 150 | 100 | 305 | 184 | 930 | Alloy Steel |
| LCSW6-55 | 55t | 20 | 465 | 150 | 100 | 305 | 188 | 940 | Alloy Steel |
| LCSW6-85 | 85t | 50 | 500 | 180 | 120 | 365 | 200 | 1050 | Alloy Steel |
| LCSW6-100 | 100t | 50 | 570 | 190 | 132 | 366 | 229 | 1230 | Alloy Steel |
| LCSW6-150 | 150t | 50 | 680 | 303 | 140 | 400 | 252 | 1311 | Alloy Steel |
| LCSW6-200 | 200t | 100 | 700 | 350 | 144 | 440 | 280 | 1380 | Alloy Steel |
| LCSW6-250 | 250t | 100 | 700 | 350 | 144 | 500 | 305 | 1880 | Alloy Steel |
| LCSW6-300 | 300t | 200 | 806 | 426 | 150 | 500 | 305 | 1955 | Alloy Steel |
| LCSW6-500 | 500t | 200 | 930 | 570 | 150 | 500 | 305 | 2065 | Alloy Steel |
(Dimensions shown are nominal and subject to tolerances)
LCSW7 Crane Load Sensor Weight:
| Model | 1t | 2t | 3t | 5t | 10t | 20t | 30t | 50/55t |
| Weight(kg) | 1.6 | 1.7 | 2.1 | 2.7 | 10.4 | 17.8 | 25 | 39 |
| Weight with shackles(kg) | 3.1 | 3.2 | 4.6 | 6.3 | 24.8 | 48.6 | 87 | 128 |
| Model | 85t | 100t | 150t | 200t | 250t | 300t | 500t | |
| Weight(kg) | 50 | 81 | 90 | 95 | 95 | 125 | 210 | |
| Weight with shackles(kg) | 195 | 321 | 435 | 585 | 822 | 865 | 1600 |
