Explosion Proof Temperature Sensor
LC709
LC709 Explosion Proof Temperature Sensor / encardio rite load cell ATEX/IECEx certified (Ex d IIC T6) for hazardous areas like oil & gas. Stainless steel construction with IP67 rating ensures corrosion/impact resistance. ±0.1% accuracy with overload protection. encardio rite load cell / explosion proof pressure sensor is ideal for tanks, reactors and safety-critical weighing.
Quantity:
LC709 Explosion Proof Temperature Sensor / encardio rite load cell ATEX/IECEx certified (Ex d IIC T6) for hazardous areas like oil & gas. Stainless steel construction with IP67 rating ensures corrosion/impact resistance. ±0.1% accuracy with overload protection. encardio rite load cell / explosion proof pressure sensor is ideal for tanks, reactors and safety-critical weighing. ( encardio rite load cell, explosion proof pressure sensor, explosion proof temperature sensor )
LC709 Explosion Proof Temperature Sensor Features:
High temperature encardio rite load cell, planar load-bearing, with a reasonable structure. The bearing mechanism is simple and reliable, easy to use, and easy to install. LC709 encardio rite load cell is widely used in weighing systems such as continuous casting ladle scales, tundish scales, and overhead crane scales in the steel industry.
LC709 Explosion Proof Temperature Sensor Dimension:mm
| Cap. | A | B | C | D | E | F | G |
| 20t | 365 | 100 | 120 | 95 | 260 | 312 | 48 |
| 50t | 450 | 120 | 130 | 105 | 298 | 398 | 68 |
| 100t | 500 | 140 | 143 | 118 | 336 | 444 | 80 |
| 150t | 560 | 160 | 158 | 133 | 372 | 500 | 94 |
| 200t | 620 | 180 | 175 | 150 | 400 | 560 | 114 |
| Cap. | H | I | K | L | M | S | N |
| 20t | 64 | 38 | 76 | 90 | Φ18 | 20 | M16×20 |
| 50t | 75 | 40 | 80 | 110 | Φ26 | 25.5 | M20×30 |
| 100t | 90 | 44 | 90 | 130 | Φ32 | 32 | M24×36 |
| 150t | 102 | 44 | 90 | 150 | Φ32 | 32 | M24×36 |
| 200t | 110 | 44 | 90 | 160 | Φ32 | 32 | M24×36 |
LC709 Explosion Proof Temperature Sensor Technical Parameter:
| Rated Load: | 20~200t | ||
| Sensitivity: | 1.5±0.1%mV/V | Operating Temp. Range: | -30~+70℃ |
| Combined Error: | ±0.5%F.S | Safe Over Load: | 150%F.S |
| Creep Error(30min): | ±0.05%~±0.1%F.S | Ultimate Over Load: | 250%F.S |
| Zero Balance: | ±1.0% F.S | Recommend Excitation: | 10~12V DC |
| Temp. Effect On Zero: | ±0.02% F.S/10℃ | Maximum Excitation: | 15V DC |
| Temp. Effect On Span: | ±0.02% F.S/10℃ | Sealing Class: | IP67/IP68 |
| Input Resistance: | 775±5Ω | Element Material: | Alloy/Stainless Steel |
| Output Resistance: | 700±2Ω | Cable: | 1m~12m |
| Insulation Resistance: | ≥5000MΩ | Citation: | GB/T7551-2008/OIMLR60 |
