Axis Load
LCX2007
Robot force sensor /axis load for robot,This precision sensor simultaneously measures forces in two perpendicular directions (X and Y axes). Featuring high accuracy, robust construction, and compact design, Robot force sensor /axis load for robot is ideal for robotics, tactile feedback, industrial automation, and biomechanical research. Delivers reliable data for advanced force control and monitoring applications.
Quantity:
Robot force sensor /axis load for robot,This precision sensor simultaneously measures forces in two perpendicular directions (X and Y axes). Featuring high accuracy, robust construction, and compact design, Robot force sensor /axis load for robot is ideal for robotics, tactile feedback, industrial automation, and biomechanical research. Delivers reliable data for advanced force control and monitoring applications. ( axis load, robot force sensor, axis load for robot )
LCX2007 Axis Load Feature:
✅ Aluminum alloy, sand blasting;
✅ High precision and sensitivity;
✅ Strong resistance to eccentric load;
✅ Independent research and development, high cost performance;
✅ Structural decoupling design, small coupling between dimensions;
✅ Analog output, which can be used with collector;
✅ Support 485 / can / USB / Ethernet / EtherCAT;
✅ Widely used in precision control of robot arm, surface grinding and polishing, precision carving processing of machining center and precision testing of medical equipment;
✅ Aluminum alloy, sand blasting;
✅ High precision and sensitivity;
✅ Strong resistance to eccentric load;
✅ Independent research and development, high cost performance;
✅ Structural decoupling design, small coupling between dimensions;
✅ Analog output, which can be used with collector;
✅ Support 485 / can / USB / Ethernet / EtherCAT;
✅ Widely used in precision control of robot arm, surface grinding and polishing, precision carving processing of machining center and precision testing of medical equipment;
LCX2007 Axis Load Dimension:
Note:The overall dimensions can be designed and customized according to customer requirements.
LCX2007 Axis Load Technical Parameter:
| Parameter | Reference Value | Parameter | Reference Value |
| Component range FX=FY: | 100N | Insulation Resistance | ＞2ΩG/100VDC |
| Output Sensitivity: | 0.5-2.0mV/V | Excitation voltage | 3-10V |
| Comprehensive accuracy: | 0.1-0.5%F.S | Temp. compensation range | -20～+80℃ |
| Nonlinear: | 0.1%F.S | Operating temp. range | -20～+80℃ |
| Lagging: | 0.1%F.S | Safety load | 120%F.S |
| Repeatability: | 0.1%F.S | Ultimate Overload | 150%F.S |
| Creep(30min): | 0.05%F.S/10℃ | Degree of protection | IP65 |
| Temp. sensitivity drift: | 0.05%F.S/10℃ | Material Science | Aluminium Alloy |
| Zero temp. drift: | 0.05%F.S/10℃ | Cable size | Ø3×3000mm |
| Input impedance: | 350±5Ω | Appearance dimension | 100×100×5mm |
| Output impedance: | 350±5Ω |
