Truck Mounted Scales
WS1101W-2
Ningbo Saintbond semi scale near me is ideal for On-Board Weighing, These used truck scales for sale near me are designed to help you get accurate weight readings on large vehicles, Ningbo Saintbond truck mounted scales offer a large weighing surface and can accommodate dual axle truck weighing and tri-axle truck trailer weighing.
Place of Origin: Ningbo,China
Brand Name: Saintbond
Certification: National and International CE Certification
Material: Aviation Aluminum
Weighing Method: Dynamic weighing and static weighing are optional;
Connection Method: Wired and wireless versions are optional;
Customizable: Capacity, Dimension, Software;
Easy and Fast Assembly;
Minimum Infrastructure Cost;
Minimum Service and Maintenance Cost;
Vehicle Weighing:
✅ Weighing of the axle of a vehicle;
✅ Calculation of the total weight of the vehicle;
✅ The overall weight of the vehicle is calculated by adding up all the axle loads;
✅ An axle can also be weighed dynamically while the vehicle drives over the axle load scale (Weigh In Motion);
Place of Origin: Ningbo,China
Brand Name: Saintbond
Certification: National and International CE Certification
Material: Aviation Aluminum
Weighing Method: Dynamic weighing and static weighing are optional;
Connection Method: Wired and wireless versions are optional;
Customizable: Capacity, Dimension, Software;
Easy and Fast Assembly;
Minimum Infrastructure Cost;
Minimum Service and Maintenance Cost;
Vehicle Weighing:
✅ Weighing of the axle of a vehicle;
✅ Calculation of the total weight of the vehicle;
✅ The overall weight of the vehicle is calculated by adding up all the axle loads;
✅ An axle can also be weighed dynamically while the vehicle drives over the axle load scale (Weigh In Motion);
Delivery
FOB
minimum order
1 set
Supply Ability
20000set / Week
Country of Origin
Ningbo,China
Stock Time
5~30Day
Quantity:
( semi scale near me,used truck scales for sale near me,truck mounted scales semi scale near me,used truck scales for sale near me,truck mounted scales semi scale near me,used truck scales for sale near me,truck mounted scales semi scale near me,used truck scales for sale near me,truck mounted scales )
Truck Mounted Scales revolutionize your hauling operations with our onboard truck scales. Installed directly on your vehicle, this integrated system provides real-time weight data on-the-go from the driver's cab. Prevent overloads, maximize payloads, and boost profitability for every single trip. Ideal for dump trucks and logistics fleets, Truck Mounted Scales's the ultimate tool for efficient, compliant, and profitable hauling.
Truck Mounted Scales revolutionize your hauling operations with our onboard truck scales. Installed directly on your vehicle, this integrated system provides real-time weight data on-the-go from the driver's cab. Prevent overloads, maximize payloads, and boost profitability for every single trip. Ideal for dump trucks and logistics fleets, Truck Mounted Scales's the ultimate tool for efficient, compliant, and profitable hauling.
Ningbo Saintbond is the world’s largest manufacturer of semi scale near me,used truck scales for sale near me,truck mounted scales in scaling technology. From complete wireless communication between scales, remote devices, and software, to industry-leading battery life, we offer a comprehensive range of products to fit any weighing application. Ningbo Saintbond sells quality, China-made in-ground and portable axle weighing systems that provide essential features for multiple industries.
Ningbo Saintbond manufactures semi scale near me,used truck scales for sale near me,truck mounted scales to weigh trucks and other commercial vehicles in a variety of industries, including transportation, logistics, construction, energy, aggregates and custom vehicle modification. Our wide range of semi scale near me,used truck scales for sale near me,truck mounted scales helps customers maintain compliance with legal vehicle weight restrictions, optimize payload to improve efficiency and safety, and save operating costs by tracking inbound and outbound shipments.
Truck Mounted Scales aluminum-alloy; Ultra thin truck mounted scales design; Easily mounted / unmounted slope; Hermetically sealed, suits different environment; Works both dynamically and statically; truck mounted scales can be used to measure axle weight and whole vehicle weight when two or four weigh-pad connected together.
WS1101W Truck Mounted Scales Dimension: mm
| Model | Size(A×B×C) | Capacity | Description |
| (mm) | (Each Weighing Pad) | (Each Pad) | |
| WS1101WB | 300×400×56.5 | 500~8000Kg | 4pcs LC348H LoadCell,10m Cable, Capacity:500/1000/1500Kg |
| 400×500×56.5 | 1000~10000Kg | 4pcs LC348H LoadCell,10m Cable Capacity:1500/2500/3000/5000Kg | |
| 450×700×56.5 | 5000~15000Kg | 6pcs LC348H LoadCell,10m Cable, Capacity:5000/10000/15000Kg | |
| 500×900×56.5 | 5000~20000Kg | 8pcs LC348H LoadCell,10m Cable, Capacity:10000/15000/200000Kg | |
| Wireless | PC Software | Optional, Customizable | |
| Mobile Bluetooth | Optional | ||
| Wireless Distance | 100~300m (Optional) | ||
WS1101W Truck Mounted Scales Technical Parameter:
| Rated load:1/2/3/5/6/10/20t | Compensated temp.range:-10~+50℃ |
| Dynamic error: 3~5%F.S (5~10km/h) | Static error:0.3~0.5%F.S |
| Static comprehensive error: 0.1~0.5%F.S | Insulation resistance:≥5000 MΩ(100VDC) |
| Rated output:1.0±0.1 mV/V | Use temp.range:-30~+80℃ |
| Non-linearity:0.2%F.S | Temp.effect on zero: 0.03 F.S/10℃ |
| Error on corners: 0.2%F.S | Temp.effect on span:0.05 F.S/10℃ |
| Repeatariy: 0.05%F.S | Safe overload:120% |
| Zero balance: ±1%F.S | Ultimate overload:150% |
| Excitation voltage:9~15VDC | Defend grade: IP66 |
| Recommended voltage:10 V | Weight Itself:12/25/28/40/55/65kg |
WS1101W Truck Mounted Scales Wireless Technical Parameter:
| A/D conversion method | Σ-Δ 24bit |
| Input signal range | –19.5mV~19.5mV |
| Load cell excitation | DC 5V |
| Max. connection number of load cell | 1~4 |
| Load cell connection mode | 4 wire |
| Operating temperature | -10°C ~40°C |
| Allowable working temperature | -40°C~70°C |
| Wireless transmission frequency | 430MHz to 470MHz |
| Wireless transmission distance | 100~300meters (In OpenPlace) |
| PC Software | Optional |
WS1101W Truck Mounted Scales Wireless Weighing Indicator (Optational )
| WI280 / WI680 Static Wireless Weighing Indicator: | WI380 Dynamic Wireless Weighing Indicator: | ||
  |  | ||
| Wireless Frequency: | 430~485MHz | ◎Full-scale temperature coefficient: 5ppm/℃; | |
| Wireless Distance: | Min:800m(In Open Area) | ◎Inner resolution: 24 bits; | |
| A/D Conversion Rate: | ≥50times/seconds | ◎Sampling speed: 200 times/second; | |
| Operating Temp. Range: | -20～+80℃ | ◎The speed of display renewal:12.5times/sec; | |
| Operating Humidity: | ≤85%RH under 20℃ | ◎System non-linearity＜0.01%; | |
| Battery Life: | ≥50 hours | ◎Impulse source of sensor: DC 5V±2%; | |
| Non-Linearity: | 0.01%F.S | ◎Operating temperature range: 0℃--40℃; | |
| Stable Time: | ≤5 Seconds | ◎Power supply sink (without the sensor): 70mA(no printing and no back lighting), 1000mA(printing); | |
| Citation: | GB/T7551-2008/ OIML R60 | ◎Power supply: built-in 8.4V/10AH leading acid accumulator, and can connect with DC source (8.4V/2A); | |
WS1101W Truck Mounted Scales Applications:
✅ Wheel weighing;
✅ Axle weighing;
✅ Vehicle weighing;
✅ Aircraft / Caravans weighing;
✅ Large Vehicles /Trucks /Tankers /Trailers /Heavy Duty Equipment;
✅ Custom sized container weighing;
✅ Wheel weighing;
✅ Axle weighing;
✅ Vehicle weighing;
✅ Aircraft / Caravans weighing;
✅ Large Vehicles /Trucks /Tankers /Trailers /Heavy Duty Equipment;
✅ Custom sized container weighing;
