Portable Trailer Weight Scales
WS1101-4
Supply Model: Original Manufacturer
Brand Name: Saintbond
Product Orgin: China
Item No.:WS1101
Shipping Port: Ningbbo,Or designated by the customer
Payment:100% payment before shipment
Capacities:Capacities:1~1000t
Material: Aluminum Alloy
Protection Class:IP67/68
Your Application, Our Custom Weigh Pad Solution:
✅ Aluminum Alloy construction: We can customize raw materials based on what the customer needs;
✅ Capacity, Size, & Output
✅ Cable Length;
✅ OEM/ODM Manufacturer;
✅ Logo customization
✅ Weighing Mode: Dynamic or Static Selectable;
✅ Connection: Wired or Wireless (Selectable);
Brand Name: Saintbond
Product Orgin: China
Item No.:WS1101
Shipping Port: Ningbbo,Or designated by the customer
Payment:100% payment before shipment
Capacities:Capacities:1~1000t
Material: Aluminum Alloy
Protection Class:IP67/68
Your Application, Our Custom Weigh Pad Solution:
✅ Aluminum Alloy construction: We can customize raw materials based on what the customer needs;
✅ Capacity, Size, & Output
✅ Cable Length;
✅ OEM/ODM Manufacturer;
✅ Logo customization
✅ Weighing Mode: Dynamic or Static Selectable;
✅ Connection: Wired or Wireless (Selectable);
Delivery
EXW FOB
minimum order
1 piece
Supply Ability
20000piece / Month
Country of Origin
China
Stock Time
15-30Day
Quantity:
portable trailer weight scales, trailer axle scale, truck scale weight per axle portable trailer weight scales, trailer axle scale, truck scale weight per axle portable trailer weight scales, trailer axle scale, truck scale weight per axle
Ningbo Saintbond Portable Trailer Weight Scales / truck scale weight per axle: Weigh Anywhere, Anytime with Precision
Ningbo Saintbond Portable Trailer Weight Scales/ truck scale weight per axle are innovative, heavy-duty weighing solutions designed for the modern logistics, agricultural, and industrial sectors. Engineered for durability, portability, and exceptional accuracy, these scales empower users to perform on-the-spot weight measurements of axle loads, trailer loads, and individual pallets directly at the site. This helps prevent overweight fines, ensures compliance with transportation regulations, and optimizes load distribution for safer journeys.
WS1101 Trailer Axle Scale Dimension:mm
| Model | Size(A×B×C) | Capacity | Description |
| (mm) | (Each Weighing Pad) | (Each Pad) | |
| WS1101WB | 300×400×56.5 | 500~8000kg | 4pcs LC348HLoadCell,10m Cable, Capacity:500/1000/1500kg |
| 400×500×56.5 | 1000~10000kg | 4pcs LC348HLoadCell,10m Cable, Capacity:1500/2500/3000/5000kg | |
| 450×700×56.5 | 5000~15000kg | 6pcs LC348HLoadCell,10m Cable, Capacity:5000/10000/15000kg | |
| 500×900×56.5 | 5000~20000kg | 8pcs LC348HLoadCell,10m Cable, Capacity:10000/15000/200000kg | |
| Wireless | PC Software | Optional, Customizable | |
| Mobile Bluetooth | Optional | ||
| Wireless Distance | 50~200m (Optional) | ||
WS1101 Trailer Axle Scale Technical Parameter:
| Rated load:1/2/3/5/6/10/20t | Compensated temp.range:-10~+50℃ |
| Dynamic error: 3~5%F.S (5~10km/h) | Static error:0.3~0.5%F.S |
| Static comprehensive error: 0.3~0.5%F.S | Insulation resistance:≥5000 MΩ(100VDC) |
| Rated output:1.0±0.1 mV/V | Use temp.range:-30~+80℃ |
| Non-linearity:0.2%F.S | Temp.effect on zero: 0.03 F.S/10℃ |
| Error on corners: 0.2%F.S | Temp.effect on span:0.05 F.S/10℃ |
| Repeatariy: 0.05%F.S | Safe overload:120% |
| Zero balance: ±1%F.S | Ultimate overload:150% |
| Excitation voltage:9~15VDC | Defend grade: IP66 |
| Recommended voltage:10 V | Weight Itself:12/25/28/40/55/65kg |
WS1101 Trailer Axle Scale Weighing Indicator: ( Optional )
| Cable Version | Wireless Version | |||
| Static | MWI01 |  | WI280 |  |
| MWI02 |  | WI680II |  | |
| Dynamic | MWI03 |  | WI380 |  |
WS1101 Trailer Axle Scale Application Scenarios:
Ningbo Saintbond Portable Scales are the ideal choice for a wide range of industries and users:
Logistics & Trucking Companies: For pre-trip load checks and compliance.
Agriculture:For weighing harvests, livestock, and fertilizer loads directly on the farm.
Waste Management & Recycling: To weigh garbage trucks and recycled materials.
Construction:For weighing construction materials, machinery, and equipment on-site.
Freight Forwarders & Shipping Ports: For quick verification of container and cargo weights.
Ningbo Saintbond Portable Scales are the ideal choice for a wide range of industries and users:
Logistics & Trucking Companies: For pre-trip load checks and compliance.
Agriculture:For weighing harvests, livestock, and fertilizer loads directly on the farm.
Waste Management & Recycling: To weigh garbage trucks and recycled materials.
Construction:For weighing construction materials, machinery, and equipment on-site.
Freight Forwarders & Shipping Ports: For quick verification of container and cargo weights.
Why Choose Ningbo Saintbond Trailer Axle Scale?
Proven Reliability: Built with industrial-grade components for long-term, dependable performance.
Cost-Effective Solution: A significant return on investment by avoiding overweight fines and improving operational efficiency.
Excellent Customer Support: We provide comprehensive technical support and after-sales service.
Customizable Options: We can tailor scale capacity, size, and features to meet your specific requirements.
Proven Reliability: Built with industrial-grade components for long-term, dependable performance.
Cost-Effective Solution: A significant return on investment by avoiding overweight fines and improving operational efficiency.
Excellent Customer Support: We provide comprehensive technical support and after-sales service.
Customizable Options: We can tailor scale capacity, size, and features to meet your specific requirements.
Ensure your loads are legal, safe, and profitable. Discover the convenience and reliability of Ningbo Saintbond Portable Trailer Weight Scales.
Ningbo Saintbond - Your Trusted Partner in Portable Weighing Solutions.
WS1101 Trailer Axle Scale Product Detail Informations:
