Bending Beam Load Cells
LC3303-1
Ningbo Saintbond's bending beam load cells are precision-engineered force sensors designed for high-accuracy weighing and force measurement applications. Utilizing the bending beam principle, these robust sensors offer excellent reliability, stability, and value, making them ideal for industrial platform scales, silo and tank weighing, batching systems, and various process control applications.
Straight from Our Factory, Customized for Your Needs.
Brand Name: Saintbond
Product Orgin: China
Item No.: LC3303
Shipping Port: Ningbbo,Or designated by the customer
Payment:100% payment before shipment
Capacities: 5~1000kg
Material: Alloy / Stainless Steel
Protection Class:IP67/68
Your Application, Our Custom Load Cell Solution:
✅ Alloy /stainless stell construction: We can customize raw materials based on what the customer needs;
✅ Capacity, Size, & Output
✅ Cable Length;
✅ ODM/OEM;
✅ Logo customization
✅ Weighing Accessories: Amplifier, Digital Signal RS232 or RS485, Weighing Indicator.
Straight from Our Factory, Customized for Your Needs.
Brand Name: Saintbond
Product Orgin: China
Item No.: LC3303
Shipping Port: Ningbbo,Or designated by the customer
Payment:100% payment before shipment
Capacities: 5~1000kg
Material: Alloy / Stainless Steel
Protection Class:IP67/68
Your Application, Our Custom Load Cell Solution:
✅ Alloy /stainless stell construction: We can customize raw materials based on what the customer needs;
✅ Capacity, Size, & Output
✅ Cable Length;
✅ ODM/OEM;
✅ Logo customization
✅ Weighing Accessories: Amplifier, Digital Signal RS232 or RS485, Weighing Indicator.
Delivery
FOB EXW
minimum order
2 pieces
Supply Ability
20000pieces / Month
Country of Origin
China
Stock Time
15 ~ 35Day
Quantity:
z6fc3 load cell, z6fc3 100kg load cell, bending beam load cells z6fc3 load cell, z6fc3 100kg load cell, bending beam load cells z6fc3 load cell, z6fc3 100kg load cell, bending beam load cells z6fc3 load cell, z6fc3 100kg load cell, bending beam load cells
Ningbo Saintbond's bending beam load cells are precision-engineered force sensors designed for high-accuracy weighing and force measurement applications. Utilizing the bending beam principle, these robust sensors offer excellent reliability, stability, and value, making them ideal for industrial platform scales, silo and tank weighing, batching systems, and various process control applications.
LC3303 Bending Beam Load Cells Dimension: mm
LC3303 Bending Beam Load Cells Technical Parameter:
| Rated Load: | 10/20/30/50/75/100/150/200/250/300/500/1000kg | ||
| Sensitivity: | (2.0±0.1%) m V/V | Operating Temp. Range: | -10~+70℃ |
| Combined Error: | ±0.02% F.S | Maximum Safe Over Load: | 150%F.S |
| Creep Error(30min): | ±0.03% F.S | Ultimate Over Load:: | 300%F.S |
| Zero Balance: | ±1% F.S | Recommend Excitation Vol.: | 10~12V DC |
| Temp. Effect On Zero: | ±0.02% F.S/10℃ | Maximum Excitation Vol.: | 15V DC |
| Temp. Effect On Span: | ±0.02% F.S/10℃ | Sealing Class: | IP68 |
| Input Resistance: | 385±5Ω | Element Material: | Alloy Steel, Stainless Steel |
| Output Resistance: | 351±2Ω | Cable: | Length=L:3m |
| Insulation Resistance: | ≥5000MΩ | Citation: | GB/T7551-2008/ OIML R60 |
LC3303 Bending Beam Load Cells Key Features & Advantages:
High Accuracy & Stability: Provides precise and repeatable measurements with excellent long-term stability.
Robust Construction: Typically manufactured from high-strength alloy steel or stainless steel, offering good resistance to off-center loads and environmental factors.
Compact & Low-Profile Design: Allows for easy installation in space-constrained applications.
Hermetically Sealed: Many models feature welded hermetic sealing (e.g., IP67, IP68 rating) to protect internal strain gauges from moisture, dust, and corrosive atmospheres.
Cost-Effective Solution: Delivers strong performance at a competitive price point for standard weighing tasks.
Easy Installation: Often designed with built-in mounting holes and optional top plates for straightforward integration.
High Accuracy & Stability: Provides precise and repeatable measurements with excellent long-term stability.
Robust Construction: Typically manufactured from high-strength alloy steel or stainless steel, offering good resistance to off-center loads and environmental factors.
Compact & Low-Profile Design: Allows for easy installation in space-constrained applications.
Hermetically Sealed: Many models feature welded hermetic sealing (e.g., IP67, IP68 rating) to protect internal strain gauges from moisture, dust, and corrosive atmospheres.
Cost-Effective Solution: Delivers strong performance at a competitive price point for standard weighing tasks.
Easy Installation: Often designed with built-in mounting holes and optional top plates for straightforward integration.
LC3303 Bending Beam Load Cells Common Applications:
Platform Scales: Bench scales, floor scales, pallet scales.
Tank & Silo Weighing: Level measurement by weight.
Batching and Filling Systems: For ingredients in food, chemical, or construction industries.
Industrial Process Control: Force monitoring in production lines.
Over/Under-weight Check Systems.
Platform Scales: Bench scales, floor scales, pallet scales.
Tank & Silo Weighing: Level measurement by weight.
Batching and Filling Systems: For ingredients in food, chemical, or construction industries.
Industrial Process Control: Force monitoring in production lines.
Over/Under-weight Check Systems.
Why Choose Saintbond?
Ningbo Saintbond focuses on producing durable and reliable weighing solutions. Their bending beam load cells are a testament to a commitment to consistent quality, rigorous testing, and providing cost-effective components for the global industrial weighing market.
Ningbo Saintbond focuses on producing durable and reliable weighing solutions. Their bending beam load cells are a testament to a commitment to consistent quality, rigorous testing, and providing cost-effective components for the global industrial weighing market.
Note: Exact specifications (capacity, dimensions, accuracy, sealing, electrical connections) may vary by specific model. Please consult the official Ningbo Saintbond datasheet or contact their sales team for precise information relevant to your application.
